Catenary Kit (Indoor) Overhead Wire Suspension Catenary

SKU # CTI

Create strong, adjustable overhead suspension lines without ceiling or substrate fixings using Gripple’s ready-to-use Catenary Kits.

Safe Working Load

Safe Working Load:

Up to 100 kg vertical load per free span

Available Wire Sizes

Available Wire Sizes:

3 mm, 6 mm

Attachment Methods

Attachment Methods:

Wall Bracket, Loop, I-Beam Clamp

Enquire Now

Product Downloads

Catenary Kit - Technical Data Pack - ENGAPAVE - CTI Certificate
View all downloads
SKU # CTI
1
1
1
1
1
1
1
1
1

Gripple Catenary Kits – Flexible Overhead Suspension Made Simple

Gripple Catenary Kits provide a fast, tool-free solution for creating overhead suspension points where traditional fixings aren’t possible.

Each kit includes two Gripple Dynamic wire joiners and pre-cut, pre-fused galvanised wire rope, ready to tension and install straight out of the box. Ideal for spanning open spaces or heritage buildings where drilling into the ceiling is restricted, the system allows you to suspend services such as ductwork, lighting, signage, acoustic panels, and more.

Used in conjunction with the Gripple C-Clip, suspension drops can be installed in seconds with a simple quarter-turn and easily repositioned along the wire. Unlike traditional U-bolt and turnbuckle systems, Gripple’s solution is faster to install, requires no hot works, and comes with tested working loads for peace of mind.

Available in 3 mm or 6 mm wire kits, Gripple Catenary Kits support up to 100 kg per span and allow for suspension at angles up to 60°, making them ideal for sloped or irregular ceilings. With full technical support and UK-manufactured quality, Gripple offers a smarter, safer, and more flexible alternative to strut grids or threaded rod systems.

Read More
Fast and Simple Install

Fast and Simple Install

Using our Gripple wire joining and tensioning technology, you can install your catenary line in minutes.

Use Alongside our Gripple C-Clip

Use Alongside our Gripple C-Clip

Using our C-Clips' quarter turn and cam technology, you can install drops and repositions safely in seconds.

Technical and Engineering Support

Technical and Engineering Support

Our technical and engineering teams are on hand from start to finish to provide: tension load and sag calculations to support structural engineering queries, along with take-offs, on-site support and installation training where needed.

Suspend at up to 60-degree Angles

Suspend at up to 60-degree Angles

Ideal for following sloping or undulating roof lines or substrates.

Ideal for Open Span Projects

Ideal for Open Span Projects

Our catenary kits and C-Clips allow you to overcome challenging installs on open span buildings with limited suspension fixing points.

Ideal for Heritage Projects

Ideal for Heritage Projects

Refurbishment projects in heritage buildings often pose suspension challenges. C-Clip and Gripple catenary kits are a great way to suspend without having to fix into heritage ceilings or beams, etc.

Fast and Simple Install

Fast and Simple Install

Using our Gripple wire joining and tensioning technology, you can install your catenary line in minutes.

Use Alongside our Gripple C-Clip

Use Alongside our Gripple C-Clip

Using our C-Clips' quarter turn and cam technology, you can install drops and repositions safely in seconds.

Technical and Engineering Support

Technical and Engineering Support

Our technical and engineering teams are on hand from start to finish to provide: tension load and sag calculations to support structural engineering queries, along with take-offs, on-site support and installation training where needed.

Suspend at up to 60-degree Angles

Suspend at up to 60-degree Angles

Ideal for following sloping or undulating roof lines or substrates.

Ideal for Open Span Projects

Ideal for Open Span Projects

Our catenary kits and C-Clips allow you to overcome challenging installs on open span buildings with limited suspension fixing points.

Ideal for Heritage Projects

Ideal for Heritage Projects

Refurbishment projects in heritage buildings often pose suspension challenges. C-Clip and Gripple catenary kits are a great way to suspend without having to fix into heritage ceilings or beams, etc.

Range Variants

Our catenary suspension kits are available in two sizes to allow suspension of higher loads if required.

Safe Working Load Safety Factor Kit Contents
3mm Kit 30 kg 5:1 Dynamic 3 Wire Joiner,
3 mm Catenary Wire
6mm Kit 100 kg 5:1 Dynamic 6, Wire Joiner,
6 mm Catenary Wire

How it Works:

See how our Catenary Kit works below, or download the technical data pack for full install guidance.

 Download the Technical Data Pack Here
Step 1: Insert the end of your wire into one channel of the Dynamic wire joiner.
Step 2: Loop the wire around your fixing point and back through the other wire channel to create your fixing.
Step 3: Use a hex key to lock off the Dynamic wire joiner.
Step 4: Use our Gripple C-Clip, which attaches tool-free to create suspension drops. (C-Clips sold separately).

Trusted by the Experts

“The pitched roof posed some challenges (for suspension). Gripple supplied their catenary system which has been fantastic…it’s saved a huge amount of time, and the slick installation has proved really positive for us.”
Darren Havard | Senior Project Manager | Imtech
Read the full case study here
“The Catenary system was selected in here for two reasons. One was it’s three straight runs, so we can maintain a nice straight, linear line which as you can see worked really well. The second is the pitch of the ceiling and using a traditional rod would have caused a design issues (based on) how we would maintain its position into the wooden soffit.”
Jack Daintith | Project Manager – Carter Electrical Services
Read the full case study here

Need Technical Support?

While catenary solutions can often feel complex or daunting, our in-house Technical Services team takes care of the full design and specification process, giving you complete confidence in your project.



Discover Our Catenary Analysis and Design Services

Related Products & Accessories

C-Clip

Catenary Suspension Clip

Max Safe Working Load: 55 kg
Available Drop Lengths : 1 – 10 m
Catenary Compatibility: 3 mm or 6 mm
View Product

Catenary Tensioning Tool

Lightweight tool designed to tension 6 mm wire rope installations with ease.

View Accessory

Catenary Wall Bracket

Ideal for attaching a D6 or 3 mm Catenary (CTI) Kit to a concrete wall or wooden beam.

View Accessory

Catenary Steel Anchor

Ideal for blind fixing into one side of a steel beam or for creating an intermediate suspension point in catenary applications.

View Accessory

GF Bracket

The GF bracket is ideal for clamping onto an I-Beam when it’s not possible to loop around with the catenary wire, or when the height of the beam is too great.

View Accessory
